Providing performance and reliability, HID's attractive, unobtrusive ThinLine II proximity card reader is housed in a two-piece, weatherproof secure potted enclosure.

125 kHz Proximity Wall Switch Reader Specifications

• The size of most standard U.S. switch plates.
• Available with Wiegand or Clock-and-Data interface.
• Potted reader suitable for indoor or outdoor use.
• Base part numbers: 5395 (Wiegand), 5398 (Clock-and-Data).
• 18" (45 cm) wire pigtail standard; consult factory for 9' (2.7 m) pigtail available by special order.

Key Features

• Easily installed and maintained with the use of NEWable covers.
• Available with a Wiegand or Clock-and-Data interface.
• Provides high reliability, consistent read range and low power consumption.
• Features include multicolor LED and internal control or host control of the LED and beeper.
• Mounts directly on metal with minimal impact on the read range performance.
• Aesthetic design available in two cover designs and four colors to match any dcor.
• Includes multilingual installation manual.
